You professional auto led light solution provider
Ultra-thin lamp head design, better concentrating effect, more standard light shadow, suitable for reflector and projector, especially projector. It minimize dark area, plus high output illuminance, the paving effect is better and perfect.
Product Specification:
These Machine accessories May you like
1>. Using automotive-grade HGL3 module light source with power up to 18W per chip. It adopts the flip-chip technology,
no golden wire, which improves the performance of the chip under high-current usage and high temperature resistance.
2>. HGL3 module light source has a light-emitting surface size of 4.62X1.44mm, which provides unprecedented color
consistency, brightness and luminous flux density. More compact beam angle, higher luminous efficiency, and light
efficiency up to 120lm/W, ideal for automotive lighting lens assemblies.
3>. The driver is built in the lamp base, with external EMC+ electronic decoding system.
4>. Using a 1.0mm double-sided PCB design, the thickness of the PCB/chip is closer to that of the halogen BULB, so
the beam pattern is equivalent to the halogen ones.
5>. Ultra-thin lamp head design, better concentrating effect, more standard light shadow, suitable for reflector and
projector, especially projector. It minimize dark area, plus high output illuminance, the paving effect is better and perfect.
6>. Comply with EMC and CE test standards.
7>. The dustproof and waterproof grade can meet the requirements of IP65 (the LED chip part should not be soaked
in water when testing, because the LED is directly exposed)
|
|
Built-in all solutions canbus decoder, canbus through rate over 99% |
|
Adjustable base design while with angle value sign, more convenient |
|
|
More places can be choosing for fixed the driver |
|
Aluminium heat dissipation dustproof and waterproof |
Technical Parameters:
Voltage: 9 ~ 32VDC / AC
Current: 1.4A/13.5V
Power: 20W
Lumen: cold state 1900lm, hot state 1400lm
Color temperature: 6000-6500K
Operating temperature: -45 ° C ~ +85 ° C
Life: >30000 hours
Quality service: 2 year warranty;
24 hours fast and comprehensive response: WhatsApp, Skype, Wechat, Viber, Instgram,
Facebook on line at your service, all questions will be responded within 24 hours；
Each product is patent authorized.
Quality assurance:
Peer testimony: We has established good cooperation with LED chip brand suppliers
such as OSRAM, Philips, Samsung, Korea CSP, and USA CREE;
Quality certification: Our products are CE and E-MARK certified, in line with
international standards;
Unipower possesses a complete and diversified product line, first-class production equipment , advanced
quality management system and insists on continuous innovation.
we start to work with customer for OEM project since 2017. The advantage of OEM project is that
you are have the exclusive right to sell that model in your country, it’s a kind of market protection,
and OEM model usually enjoys longer profit gaining period, not easy to be replaced by market.
※ More we can support:
Our company will select an exclusive product to you and only provide to you only. At the same time, if we get
inquiry from your country, we will let you contact them directly.
Our company provide laser logo, customized package, unique design OEM service. Our designer can could provide
you poster, promotion manual, installation video ect.
Q: Do you supply sample?
A: Yes, sample is available to test the products brightness and pattern beam.
Q: Can I do my private logo or my own box?
A: Sure, When your order MOQ reach 10sets, it can be laser your private logo.
Q: How long would the delivery cost?
A: We support many delivery lines ,such as DHL, UPS, Fedex，EMS，TNT, sea，special airline.
For Some hot selling headlight which is kept in stock, we could arrange shipment within 2 working days.
